| CPU (MAX SUPPORT) |
i9 |
| SOCKET |
1700 |
| CHIPSET |
Intel® B660 Chipset |
| DDR5 MEMORY |
6200+(OC) , 6000(OC) , 5800(OC) , 5600(JEDEC) , 5400(JEDEC) , 5200(JEDEC) , 5000(JEDEC) , 4800(JEDEC) MHz |
| MEMORY CHANNEL |
Dual |
| DIMM SLOTS |
4 |
| MAX MEMORY (GB) |
128 |
| PCI-E X16 |
2 |
| PCI-E X1 |
1 |
| SATAIII |
6 |
| M.2 SLOT |
3 |
| RAID |
0/1/5/10 |
| LAN |
1x Realtek® 8125BG 2.5G LAN |
| WIFI & BLUETOOTH |
Intel® Wi-Fi 6E module |
| USB 3.2 PORTS (FRONT) |
1(Gen 2, Type C), 1(Gen 1, Type A) |
| USB 3.2 PORTS (REAR) |
1(Gen 2×2, Type C), 4(Gen 2, Type A) |
| USB 2.0 PORTS (FRONT) |
4 |
| USB 2.0 PORTS (REAR) |
4 |
| AUDIO PORTS (REAR) |
Realtek® ALC1220P Codec |
| DISPLAYPORT |
1 |
| HDMI |
1 |
| DIRECTX |
12 |
| CROSSFIRE |
Y |
| OPERATING SYSTEM |
Support for Windows® 11 64-bit, Windows® 10 64-bit |
| FORM FACTOR |
ATX |
